Getting started with your
SMS-920 orSMS-930
Here is the USB installation of the printer driver.
Do you want to set up the printer afterwards for use via a LAN connection? Then watch the relevant instruction video (Step 6 | Instructional videos).
1
Get your printer ready but do not switch it on and do not connect it to your computer yet.
2
Download the SMS printer driver and start the SMS-Printer-Drivers.exe file
(Downloading error? Right-click and select “Save as”)
2
Download the SMS printer driver and unpack the SMS-Printer-Drivers-2024.zip file and start the PrnInst.exe installation file
(Make sure to install the .exe installation file with administrator rights)
3
Click Unzip and then follow the installation wizard
(Click to enlarge)
3
Now follow the installation wizard
(Click to enlarge)
4
Choose Install Printer Driver and select the option USB port
(Click to enlarge)
4
Choose Install Printer Driver and select the option USB port
(Click to enlarge)
5
Connect the printer to your PC via the USB cable, then turn the printer ON
(Click to enlarge)
The wizard will recognise your SMS printer and after this, the printer driver will be installed automatically!
(Failed to install? Contact support@rebo.nl or call +31 (0)35 – 2400 137)
Here is the USB installation of the printer driver.
Do you want to set up the printer afterwards for use via a LAN connection? Then watch the relevant instruction video (Step 6 | Instructional videos).
1
Get your printer ready but do not switch it on and do not connect it to your computer yet.
2
Download the SMS printer driver and start the SMS-Printer-Drivers.exe file
(Downloading error? Right-click and select “Save as”)
2
Download the SMS printer driver and unpack the SMS-Printer-Drivers-2024.zip file and start the PrnInst.exe installation file
(Make sure to install the .exe installation file with administrator rights)
3
Click Unzip and then follow the installation wizard
(Click to enlarge)
3
Now follow the installation wizard
(Click to enlarge)
4
Choose Install Printer Driver and select the option USB port
(Click to enlarge)
4
Choose Install Printer Driver and select the option USB port
(Click to enlarge)
5
Connect the printer to your PC via the USB cable, then turn the printer ON
(Click to enlarge)
The wizard will recognise your SMS printer and after this, the printer driver will be installed automatically!
(Failed to install? Contact support@rebo.nl or call +31 (0)35 – 2400 137)
Install the NiceLabel software so you can design and print labels.
Tip: Keep your NiceLabel licence code in reach.
1
Download your software version below and start the installer.
NiceLabel 10
NiceLabel 2019
(Error while downloading? Right-click and select “Save as”)
2
Go through the installation and select the option:
License key or Hardware key and click Next
(Click to enlarge)
3
Enter your NiceLabel license key and click Next
(Click to enlarge)
4
Determine which software modules you wish to install and click Next
(If you have a PowerForms Suite licence and it concerns an installation on a workstation on which Automation will not run: uncheck the Automation module.)
(Click to enlarge)
5
Choose the location where you want to install NiceLabel and click Next
6
The software will now be installed. When the installation is complete, launch the application NiceLabel Designer by clicking the shortcut on your desktop..
7
You will now see the activation wizard:
At Activate license, click on Activate
At License Key, click on Activate
Fill in your details and click ActivateAre you going to activate a multi-user licence? Please click here
(Click to enlarge)
NiceLabel is now ready for use.
(Unsuccessful? Please contact support@rebo.nl or call +31 (0)35 – 6016941)
Install the NiceLabel software so you can design and print labels.
Tip: Keep your NiceLabel licence code in reach.
1
Download your software version below and start the installer.
NiceLabel 10
NiceLabel 2019
(Error while downloading? Right-click and select “Save as”)
2
Go through the installation and select the option:
License key or Hardware key and click Next
(Click to enlarge)
3
Enter your NiceLabel license key and click Next
(Click to enlarge)
4
Determine which software modules you wish to install and click Next
(If you have a PowerForms Suite licence and it concerns an installation on a workstation on which Automation will not run: uncheck the Automation module.)
(Click to enlarge)
5
Choose the location where you want to install NiceLabel and click Next
6
The software will now be installed. When the installation is complete, launch the application NiceLabel Designer by clicking the shortcut on your desktop..
7
You will now see the activation wizard:
At Activate license, click on Activate
At License Key, click on Activate
Fill in your details and click ActivateAre you going to activate a multi-user licence? Please click here
(Click to enlarge)
NiceLabel is now ready for use.
(Unsuccessful? Please contact support@rebo.nl or call +31 (0)35 – 6016941)
The utilities below are required or recommended when using NiceLabel label software to make it even easier for you to design and print your labels.
1
SVG Explorer
Windows Explorer plug-in for previewing SVG images.
2
Graphic Symbols Library V4
Exclusive to our customers: thousands of industrial & technical symbols, official seals and logos in high quality.
Do you not see an example of these symbols? In your Windows Explorer, click the
Right click
>
View
>
Normal icons
or
Large icons
Old clipart (WMF)
Looking for old symbols that were in our previous version(s) of clipart? You can download them below. Note: These do not meet the latest ISO standards.
Do you not see an example of these symbols? Download and install
this free tool
. After this, in your Windows Explorer, click the
Right click
>
View
>
Normal icons
or
Large icons
3
Microsoft Database Engine
Required to associate NiceLabel with a Microsoft Excel or Access file.
The utilities below are required or recommended when using NiceLabel label software to make it even easier for you to design and print your labels.
1
SVG Explorer
Windows Explorer plug-in for previewing SVG images.
2
Graphic Symbols Library V4
Exclusive to our customers: thousands of industrial & technical symbols, official seals and logos in high quality.
Do you not see an example of these symbols? In your Windows Explorer, click the
Right click
>
View
>
Normal icons
or
Large icons
Old clipart (WMF)
Looking for old symbols that were in our previous version(s) of clipart? You can download them below. Note: These do not meet the latest ISO standards.
Do you not see an example of these symbols? Download and install
this free tool
. After this, in your Windows Explorer, click the
Right click
>
View
>
Normal icons
or
Large icons
3
Microsoft Database Engine
Required to associate NiceLabel with a Microsoft Excel or Access file.
The steps below describe how the materials are placed.
The steps below describe how the materials are placed.
Watch instructional video
Watch in this instruction video how to place the label material and print ribbon.
(Do you still have questions after viewing? Please contact our support department)
(Click to enlarge)
Watch instructional video
Watch in this instruction video how to place the label material and print ribbon.
(Do you still have questions after viewing? Please contact our support department)
(Click to enlarge)
The steps below describe how the materials are placed.
The steps below describe how the materials are placed.
Watch instructional video
Watch in this instruction video how to place the label material and print ribbon.
(Do you still have questions after viewing? Please contact our support department)
(Click to enlarge)
Watch instructional video
Watch in this instruction video how to place the label material and print ribbon.
(Do you still have questions after viewing? Please contact our support department)
(Click to enlarge)
NiceLabel settings
Perform the following steps:
1
Open NiceLabel Designer and goto File>Options
2
Click on tab Designer
3
At Opening modus selection option Display each document in its own window.
At Source printer settings selectoption Printer settings saved in the label .
4
ClickOK to save the changes
Material-specific printer settings
In most cases, the printer’s default settings are sufficient and you do not need to change anything.
Should it be necessary, you can adjust these settings as required.
Open the printer driver settings to change e.g. cutter/tear strip, heat, speed, sensor choice for material type (media type):
1
Open or create a label and click on the printer icon
2
The tab Options (Options)include heat and speed settings.
The tab Advanced Settings (Advanced Setup) include media type and scissor/scissor strip settings.
(Click to enlarge)
Continuous roll of tape
If you use continuous rolls of tape then the Media type must be set to“Continuous”
Roll of die-cut labels with gaps
For rolls of labels without marks/stripes on the back Media type must be set to“Label with gaps”
Roll with marks/stripes or cut-outs
Are you using material with cut-outs or marks/stripes on the back side? Select Media type “Label with marks”
NiceLabel settings
Perform the following steps:
1
Open NiceLabel Designer and goto File>Options
2
Click on tab Designer
3
At Opening modus selection option Display each document in its own window.
At Source printer settings selectoption Printer settings saved in the label .
4
ClickOK to save the changes
Material-specific printer settings
In most cases, the printer’s default settings are sufficient and you do not need to change anything.
Should it be necessary, you can adjust these settings as required.
Open the printer driver settings to change e.g. cutter/tear strip, heat, speed, sensor choice for material type (media type):
1
Open or create a label and click on the printer icon
2
The tab Options (Options)include heat and speed settings.
The tab Advanced Settings (Advanced Setup) include media type and scissor/scissor strip settings.
(Click to enlarge)
Continuous roll of tape
If you use continuous rolls of tape then the Media type must be set to“Continuous”
Roll of die-cut labels with gaps
For rolls of labels without marks/stripes on the back Media type must be set to“Label with gaps”
Roll with marks/stripes or cut-outs
Are you using material with cut-outs or marks/stripes on the back side? Select Media type “Label with marks”
Watch the instructional videos to get familiar with your printer and software.
Do you have questions that are not being answered here? Contact our support department.
Loading the supplies
This video shows you clearly how to position tapes & printer ribbons.
NiceLabel basics
Learn the basics about objects, tools, alignment and the integration of variable data.
Printing from Excel (file)
See how to create an Excel database connection with variable data.
Managing dynamic data
Learn how to use Dynamic Data Manager to manage data connections.
Watch the instructional videos to get familiar with your printer and software.
Do you have questions that are not being answered here? Contact our support department.
Loading the supplies
This video shows you clearly how to position tapes & printer ribbons.
NiceLabel basics
Learn the basics about objects, tools, alignment and the integration of variable data.
Printing from Excel (file)
See how to create an Excel database connection with variable data.
Managing dynamic data
Learn how to use Dynamic Data Manager to manage data connections.
Do you want to use ready-made templates that you can easily edit and print?
Download one of the labels below by clicking on an image.
(Can’t download this file? Right click on an image and select Save As)
A4 Location label
A4 Machine plate
Equipment ID label
Maintenance tag
Safety instruction
Machine plate
Wire Wrap
Instruction card
Rating plate
Inspection sticker
Load diagram
Pipe marker
Pipe marker (GHS)
Multi-level location label
Machine safety label
Magnetic tape barcode
Machine Tag label
Machine ID label
Escape route label
Crate label
LEAN 5S label
Keep distance v1
Keep distance v2
Keep distance v3
Corona rules
Please wait here
Hygiene rules (round)
Please keep distance
Face mask mandatory
Mandatory face mask
Hygiene rules v1
Hygiene rules v2
Please do not sit here
Do you want to use ready-made templates that you can easily edit and print?
Download one of the labels below by clicking on an image.
(Can’t download this file? Right click on an image and select Save As)
A4 Location label
A4 Machine plate
Equipment ID label
Maintenance tag
Safety instruction
Machine plate
Wire Wrap
Instruction card
Rating plate
Inspection sticker
Load diagram
Pipe marker
Pipe marker (GHS)
Multi-level location label
Machine safety label
Magnetic tape barcode
Machine Tag label
Machine ID label
Escape route label
Crate label
LEAN 5S label
Keep distance v1
Keep distance v2
Keep distance v3
Corona rules
Please wait here
Hygiene rules (round)
Please keep distance
Face mask mandatory
Mandatory face mask
Hygiene rules v1
Hygiene rules v2
